Properties

  • Fast
  • Liquid
  • THF-free

Application

Suitable for:

For joining pipes, sockets and fittings with interference fit in pressure and drainage systems. With special round pipe brush and wiper for a quick, clean, and optimal application. Suitable for diameters ≤ 160 mm (pressure ≤ 90 mm). Max. 16 bar (PN 16). Maximal tolerances: 0.3 mm diametrical clearance / 0.2 mm press fit. Suitable for e.g. pipe systems conforming to EN 1329, 1452, 1453 and 1455.

Handling

Before use

Working conditions

Do not use in temperatures ≤ +5°C.

Coverage

Indication of the number of joints per 1 L:

During use

Directions For Use

1. Cut pipes square, chamfer edges and deburr. 2. Clean surfaces with Griffon Cleaner and Cleaner Cloth. 3. Apply cement rapidly and evenly all around (4-6x) on both surfaces (pipe thick, socket thin). 4. Assemble joint immediately. Remove excess cement. Let joints rest for 10 minutes. Close packaging properly immediately after use.

Points of attention

Use a suitable size of brush for the diameter to be bonded.

After use

Stains/residue

Remove adhesive stains with Griffon Cleaner and Cleaner Cloth.

Storage conditions

Stored in unopened packaging between +5°C and +25°C. Best Before Date (MM/YY): see packaging. Close packaging properly after use and store in a dry, cool, and frost-free location.
